EntryProx 4045CGNU0
EntryProx plus 10 Keytags 4045CGKU0
EntryProx plus 20 ProxCard II 4045CGCU0

5.25” x 2.75” x 1.625” (13.33 cm x 6.98 cm x 4.1 cm)

ProxCard® II card - up to 9” (22 cm)
ISOProx® II card - up to 8” (20 cm)
DuoProx® II card - up to 8” (20 cm)
Smart ISOProx® card - up to 8” (20 cm)
Smart DuoProx® card - up to 8” (20 cm)
HID Proximity and MIFARE® card - up to 8” (20 cm)
ProxCard® Plus card - up to 4” (10 cm)
ProxKey® II keyfob - up to 4” (10 cm)
MicroProx® Tag - up to 4” (11 cm)
*Depending on local installation conditions.

125 kHz

Canada/UL 294 Listed, FCC Certification, United States,
Canada Certification, CE Mark, EU and CB Scheme Electrical
Safety (EN60950 and IEC60950 ITE Electrical Safety)
Fifteen EU Countries under the R&TTE Directive (EN 300 330
- SRD, and ETS 300 683 - EMC), Australia C-Tick (pending),
New Zealand (pending), Taiwan (pending)

10 - 15 VDC, reverse voltage protected
Linear supply recommended, 150 mA @ 12 VDC
